| 尺寸50 to 135155 to 225* 若要选择其它尺寸, 请点选上方的超链接 规格描述CTB 入力在上出力实心入力实心速比 1:10, 1:15, 1:20, 1:30, 1:40, 1:50, 1:60 |
| 单位：mm |
 |
| Size | Ratio | A | AB | AC | AD | B | BB | BC | BD | CA | CB | CC | CD | CE | Z |
| 50 | 1/10 | 181 | 107 | 110 | 140 | 147 | 95 | 95 | 120 | 175 | 80 | 50 | 130 | 15 | 11 |
| 60 | 1/15 | 204 | 124 | 120 | 150 | 168 | 110 | 105 | 130 | 200 | 90 | 60 | 150 | 18 | 11 |
| 70 | 1/20 | 235 | 140 | 150 | 190 | 196 | 130 | 115 | 150 | 235 | 105 | 70 | 175 | 20 | 15 |
| 80 | 1/30 | 265 | 160 | 180 | 220 | 216 | 140 | 135 | 170 | 260 | 120 | 80 | 200 | 20 | 15 |
| 100 | 1/40 | 328 | 192 | 220 | 270 | 262 | 170 | 155 | 190 | 359 | 150 | 100 | 250 | 25 | 15 |
| 120 | 1/50 | 389 | 230 | 260 | 320 | 288 | 190 | 180 | 230 | 425 | 180 | 120 | 300 | 30 | 18 |
| 135 | 1/60 | 435 | 260 | 290 | 350 | 320 | 210 | 200 | 250 | 478 | 215 | 135 | 350 | 30 | 18 |
|
| Size | Input Shaft | Output Shaft | Oil | Weight | Rating | Download | |||||
| HS | U | T*V | LS | S | W*X | CAD | |||||
| 50 | 30 | 12 | 4 * 2.5 | 40 | 17 | 5 * 3 | 0.4 | 6.5 | | | |
| 60 | 40 | 15 | 5 * 3 | 50 | 22 | 7 * 4 | 0.5 | 8.5 | | | |
| 70 | 40 | 18 | 5 * 3 | 60 | 28 | 7 * 4 | 0.8 | 14 | | | |
| 80 | 50 | 22 | 7 * 4 | 65 | 32 | 10 * 4.5 | 1.2 | 19 | | | |
| 100 | 50 | 25 | 7 * 4 | 75 | 38 | 10 * 4.5 | 2.2 | 38 | | | |
| 120 | 65 | 30 | 7 * 4 | 85 | 45 | 12 * 4.5 | 4.2 | 64 | | | |
| 135 | 75 | 35 | 10 * 4.5 | 95 | 55 | 15 * 5 | 6 | 85 | | | |
