特点 | Features |
l 通过LED显示屏可以轻松查看相关信息 | m Easy-to-see LED display offers superb visual recognition |
l 可稳定实现极微流量控制 | m Superb feed of extremely small amount of fluid |
l 外部输入信号RS232C、DC1-5V、 DC4020mA | m External input signal RS232C, DC1-5V, DC4-20mA |
l 极小脉动流量 | m Extremely small pulsating flow |
参数 | Specifications |
型号 Model | 流量(ml/min.) Flow rate(ml/min.) | **输出压力(MPa) Max Delivery pressure (MPa) | 接液部分材质 Wetted part material | 外形尺寸(mm) Dimensions(mm) | 重量 Weight | 电源 Power | 外部输入 External input |
NRX-01-L | 0.001~1.0 | 2 | SUS316,蓝宝石,橡胶,陶瓷,PTFE,PEEK SUS316/Sapphire/Ruby/Ceramics/PTFE/PEEK | 133(W) 192(H) 366(D) | 5Kg | AC100 2A | RS232C DC1-5V DC4-20mA BRAKE |
NRX-01-M | 0.001~1.0 | 20 | |||||
NRX-01-H | 0.001~1.0 | 35 | |||||
NRX-10-L | 0.01~10 | 2 | |||||
NRX-10-M | 0.01~10 | 20 | |||||
NRX-10-H | 0.01~10 | 35 | |||||
NRX-01U-L | 0.001~1.0 | 2 | PEEK,橡胶,蓝宝石,陶瓷,PTFE, 氟橡胶 PEEK/Ruby/Sapphire/Ceramics/PTFE/ Fluororubber | ||||
NRX-01U-M | 0.001~1.0 | 10 | |||||
NRX-10U-l | 0.01~10 | 2 | |||||
NRX-10U-M | 0.01~10 | 10 |
如需进一步了解详情,致电:01082021249
