尺寸 | ||
| 40 ~ 135155 ~ 250300 ~ 400 | ||
 | ||
| * 若要选择其它尺寸, 请点选上方的超链接 |
| 规格描述 | ||
| CTA 入力在下出力实心入力实心速比 1:10, 1:15, 1:20, 1:30, 1:40, 1:50, 1:60 | ||
| 单位：mm |
 |
| Size | A | AB | AC | AD | B | BB | BC | BD | CA | CB | CC | CD | CE | Z |
| 40 | 139 | 83 | 70 | 88 | 120 | 78 | 80 | 102 | 135 | 70 | 40 | 30 | 10 | 9 |
| 50 | 181 | 107 | 110 | 140 | 147 | 95 | 95 | 120 | 180 | 100 | 50 | 50 | 18 | 11 |
| 60 | 204 | 124 | 120 | 150 | 168 | 110 | 105 | 130 | 210 | 120 | 60 | 60 | 20 | 11 |
| 70 | 235 | 140 | 150 | 190 | 196 | 130 | 115 | 150 | 240 | 140 | 70 | 70 | 22 | 15 |
| 80 | 265 | 160 | 180 | 220 | 216 | 140 | 135 | 170 | 278 | 160 | 80 | 80 | 23 | 15 |
| 100 | 325 | 192 | 220 | 270 | 260 | 170 | 155 | 190 | 376 | 200 | 100 | 100 | 25 | 15 |
| 120 | 389 | 230 | 260 | 320 | 291 | 190 | 180 | 230 | 435 | 240 | 120 | 120 | 30 | 18 |
| 135 | 435 | 260 | 290 | 350 | 320 | 210 | 200 | 250 | 490 | 270 | 135 | 135 | 30 | 18 |
|
| Size | Input Shaft | Output Shaft | Oil | Weight | Rating | Download | |||||
| HS | U | T * V | LS | S | W * X | CAD | |||||
| 40 | 25 | 12 | 4 * 2.5 | 35 | 16 | 5 * 3 | 0.2 | 4 | | | |
| 50 | 30 | 12 | 4 * 2.5 | 40 | 17 | 5 * 3 | 0.22 | 7 | | | |
| 60 | 40 | 15 | 5 * 3 | 50 | 22 | 7 * 4 | 0.32 | 10 | | | |
| 70 | 40 | 18 | 5 * 3 | 60 | 28 | 7 * 4 | 0.55 | 15 | | | |
| 80 | 50 | 22 | 7 * 4 | 65 | 32 | 10 * 4.5 | 0.77 | 20 | | | |
| 100 | 50 | 25 | 7 * 4 | 75 | 38 | 10 * 4.5 | 1.53 | 38 | | | |
| 120 | 65 | 30 | 7 * 4 | 85 | 45 | 12 * 4.5 | 2.4 | 63 | | | |
| 135 | 75 | 35 | 10 * 4.5 | 95 | 55 | 15 * 5 | 3.25 | 83 | | | |
