火龙陶瓷纤维毯Huolong Ceramic Fiber Spun Blanket
产品描述：Description
◎火龙陶瓷纤维毯，采用连续化生产，经针刺后纤维交织均匀、抗拉强度高，不含任何结合剂。
◎不同体积密度、不同厚度的针刺毯为用户提供了宽阔的选材范围，以获得**隔热结构和效益。
◎火龙陶瓷纤维毯具有良好的抗化学侵蚀能力（氢氟酸、磷酸和强碱Na2O,K2O除外）。
◎火龙陶瓷纤维毯的性能不受油蚀的影响，经过烘干即可恢复其热性能和物理特性。
Huolong Ceramic Fiber Blanket was adopted continuous processing method，the fiber interweaved shape after being needled，which of excellent tensile strength. The blanket contains not any bonding agent 。
Our needled blanket has various density and thickness so that our client can have many choices, which will bring the perfect insulating framework and profit.
Huolong Ceramic Fiber Blanket can resist the chemical species well, but not the Hydrofluoric Acid, Phosphoric Acid and Strong Base.
Huolong Ceramic Fiber Blanket have excellent capability of resisting the oil, after being dried it will repossess the thermal characteristic and the physical feature.
产品种类：Product Series
◎1050陶瓷纤维甩丝毯HLGX-112
◎1260陶瓷纤维甩丝毯HLGX-212
◎高纯陶瓷纤维甩丝毯HLGX-312
◎高铝陶瓷纤维甩丝毯HLGX-412
◎含锆陶瓷纤维甩丝毯HLGX-512
1050 Ceramic Fiber Spun Blanket HLGX-112
1260 Ceramic Fiber Spun Blanket HLGX-212
High Purity Ceramic Fiber Spun Blanket HLGX-312
High Aluminum Ceramic Fiber Blown Blanket HLGX-412
High Zirconium Ceramic Fiber Spun Blanket HLGX-512
产品特点：Characteristic◎优良的化学稳定性
◎优良的热稳定性
◎优良的抗拉强度
◎低热容量
◎低导热率
Excellent Chemical Stability Excellent Thermal Stability Excellent Tensile Strength
Low Heat Storage Low Thermal Conductivity
典型应用：Application
◎工业窑炉壁衬、背衬材料，窑炉砌体膨胀缝、炉门、顶盖绝热密封
◎高温管道的绝热材料
◎模块/折叠块加工材料
The material of wall lines and back lines of industrial furnace and the sealing and insulating material of expanded gaps of furnace wall, furnace door, furnace top lid, etc.
Insulating materials of high temperature tubes
Excellent materials to produce module
技术指标Technical Index：
分类温度 Classification Temperature | 1050 | 1260 | 1400 | ||||
产品代码Code | HLGX-112 | HLGX-212 | HLGX-312 | HLGX-422 | HLGX-512 | ||
加热**线变化(%) Shrinkage on Heating (%) | 950℃×24h≤-3 | 1050℃×24h≤-3 | 1100℃×24h≤-3 | 1200℃×24h≤-3 | 1280℃×24h≤-3 | ||
理论导热系数 Theoretical Thermal Conductivity (W/m·k)（128kg/m3） | (200℃average) | 0.045-0.060 | 0.052-0.070 | ||||
(400℃average) | 0.085-0.110 | 0.095-0.120 | |||||
(600℃average) | 0.152-0.20 | 0.164-0.210 | |||||
理论体积(kg/m3) Theoretical Density (kg/m3) | 96/128 | 128 | 96/128 | ||||
产品规格(mm) Specification (mm) | 3600/7200/15000×610/1220×10/20/25/30/40/50 （422δ: 10/20/25/30） | ||||||
抗拉强度（25mm厚）MPa Tensile Strength（25mm thick）MPa | ≥0.04 | ||||||
包装Package | 内塑料袋外编织袋Plastic Bag Inside, Braided Bag Outside | ||||||
